Patents

McRobert Contracting Services holds a number of Australian patents associated with the lining of structures.

Access Chamber Refurbishments

Patent No AU2016253601
Title Method of lining a utilities manhole
Type Standard
Status Filed
Filing Date 02/11/2016
Patent No AU2016101938
Title  Method of lining a utilities manhole
Type  Innovation
Status  Granted
Filing Date  02/11/2016
Patent No  AU2009222579
Title Method of lining a utilities manhole
Type  Standard
Status  Accepted
Filing Date 02/10/2009

This invention relates to a method of lining a utilities manhole, such as, but not limited to, a manhole for a sewer.

To see how this method works, head on over to our Access Chamber Refurbishments page.

Sewer Pump Station Refurbishments

Patent No AU2014250707
Title A system and method for lining a structure
Type Standard
Status Filed
Filing Date 17/10/2014

This invention is a system and method for lining a structure such as, but not limited to, a utilities pipe, pit or well.

In broad terms, the method and system facilitate the refurbishment or construction of a structure by using the lining material itself as the form work for the settable material used to reform the structure insitu.

For more details on how we do this, check out our Sewer Pump Station Refurbishments page.

Workshop Fabrication

Patent No AU2017200554
Title A Welding Carriage and Welding Apparatus
Type Standard
Status Filed
Filing Date 27/01/2017
Patent No AU2016900310
Title Welding apparatus
Type Provisional
Status Filed
Filing Date 01/02/2016

This invention relates to a welding carriage and a welding apparatus for heat welding a polymer strip onto a substrate. This is used for welding grout anchor strips onto PVC sheeting during the prefabrication process for both access chamber refurbishments and sewer pump station refurbishments.

To see it in action, check out our Workshop Fabrication page.

Scaffolding Systems

Patent No AU2010101120
Title Scaffolding system
Type Innovation
Status Granted
Filing Date 13/10/2010

This invention relates to a scaffolding system, and in particular, but not exclusively, to a scaffolding system suitable for use in a confined space which has restricted ingress and egress.

For more information, head over to our Scaffold and Bracing Systems page.

Additional Patents

Patent No AU2017900680
Title Sewer Access Chamber Protection System
Type Standard
Status Filed
Filing Date 28/02/2017

This invention relates to a system for protecting the cover of a chamber, such as a sewer access chamber or a manhole, from fluid contact. It is also designed to prevent odours from escaping. This system is designed to be implemented into access chambers or manholes which already have a plastic lining.

Consisting of a frame and lid system, the frame is welded onto the existing frame of the access chamber or manhole. A lid is then secured onto the frame, underneath the existing gatic lid. The original lid is then secured above the entire system, ensuring all fluids and odours have no means of escape.

sewer access chamber protection system 1
Sewer access chamber protection system
sewer access chamber protection system
Patent No AU2011101397
Title A rotary welding system
Type Innovation
Status Granted
Filing Date 21/10/2011

This invention is for a rotary welding system to weld on the inside surface of a pipe.

This system was designed to address issues of fatigue management, while improving worker safety and productivity. The extruder welders required to perform this work weigh 8-10kgs, and require a large amount of energy and strength to continuously weld vertical joints around the circumference of large diameter pipes. The rotary welding system supports the entire weight of the welder, allowing the operator to concentrate solely on speed and direction during operation.
